46mm Side-Mount Drawer Slides

Steel ball bearing slide

3 section extension

Lever disconnect

32mm System Hole

Detent-in

1/2'' installation space

12''~24'' loading for 45kg

Item No.	Slide Length A		Slide Travel B (mm)
Item No.	(inches)	(mm)	Slide Travel B (mm)
LH46RN10	10’’	250	250
LH46RN12	12’’	300	302
LH46RN14	14’’	350	354
LH46RN16	16’’	400	400
LH46RN18	18’’	450	452
LH46RN20	20’’	500	515
LH46RN22	22’’	550	558
LH46RN24	24’’	600	600
LH46RN26	26’’	650	650
LH46RN28	28’’	700	705
